Frame Tents Aluminium Structure Outdoor Event Tent For Large-Scale
Events
Structure tents are extremely popular for large-scale events (and
at a large variety of other applications) because they feature
large unobstructed interior spaces that maximize event or
application utility, as well as wide width options and near-endless
modular lengths. They are engineered structures featuring great
modular stability, and feature an assembled box beam framework that
supports the fabric roof. This delivers a more robust construction
that makes structure tents suitable for longer-term applications
and larger events.
Tent Specifications
| Item | Details |
| Frame material | Hard Pressed Extruded Aluminum Alloy 6061/T6(15HW) |
| Side Wall Cover | PVC walls,glass wall,ABS wall,sandwich pannel ect |
| Roof Cover | 850g/s double PVC-coated polyester textile |
| Connectors | Hot-DIP Galvanized/strong hot-dip galvanized steel. |
| Service Life | More than 15 years |
| Snow load | 75kg/sqm (snow can't stay if use big degree roof pitch design). |
| Doors | double-wing glass door, single-wing glass door, glass fire door,
aluminium door, rolling shutter |
Tent Measurement Chart
Tent Width:3m-50m
Tent Length no limited. Extended length of tent by 5m a bay, such as
15m,20m,25m,30m,35m,40m......
Customized size is available
| Product Code | Tent Span | Tent partition width | Eave height | Roof height | Angle of Roof | Aluminium profile size(mm) |
| SHB-6 | 6 | 3 | 2.6 | 3.7 | 20° | 84X48X3 |
| SHB-8 | 8 | 3 | 2.6 | 4 | 20° | 84X48X3 |
| SHB-9 | 9 | 3 | 2.6 | 4.3 | 20° | 84X48X3 |
| SHB-10 | 10 | 5 | 2.6 | 4.8 | 20° | 122X68X3 |
| SHB-12 | 12 | 5 | 3 | 5.2 | 20° | 122X68X3 |
| SHB-15 | 15 | 5 | 4 | 6.4 | 18° | 166X88X3 |
| SHB-18 | 18 | 5 | 4 | 6.9 | 18° | 203X112X4 |
| SHB-20 | 20 | 5 | 4 | 7.2 | 18° | 203X112X4 |
| SHB-25 | 25 | 5 | 4 | 8 | 18° | 203X112X4 |
| SHB-30 | 30 | 5 | 4 | 8.9 | 18° | 250X120X5 |
| SHB-35 | 35 | 5 | 4 | 9.8 | 18° | 300X120X5 |
| SHB-40 | 40 | 5 | 4 | 10.6 | 18° | 300X120X5 |
| SHB-45 | 45 | 5 | 4 | 11.4 | 18° | 300X120X5 |
| SHB-50 | 50 | 5 | 4 | 12.3 | 18° | 350X120X5 |
| SHB-55 | 55 | 5 | 4 | 13.2 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 4 | 14.4 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 6 | 16.4 | 18° | 400X120X5 |
FAQ
Q: How can I place order?
After all details has been discussed and confirmed with us, we can
start production from the date of payment deposit 30% received.
After finished production, you can pay the balance payment, we will
arrange shipment.
The payment terms is 30% depoit and 70% balance before shipment by
T/T transfer.
Q: What's the production lead time?
Our production lead time is 7-30 days depends on the exact order.
Q: What about the shipment?
We provide CIF, FOB or EXW.
CIF: We arrange shipment from our factory to your sea port.
FOB: We arrange shipment from our factory to the sea port from our
side.
EXW: We don’t arrange shipment and you will work the shipment with
your shipping agent.
Q:Do you have certifications?
Yes, we have SGS certificates, Including low temperature bending resistance certification,
Scarlett 650g anti-UV4-5 certified, UV-resistant and certified mold proofing antibacterial, flame retardant
certification 650gsm-B1, 850gsm-M2 flame retardant certification.
Q: Can you print our logos on the tent?
Yes. Customized logos can be printed on the tent fabric according
to your requirements.
Q: Is that factory price?
Yes. We assure you all prices are based on factory.
Q: Does your tent be able to installed repeatedly? What is the life
span?
Our tents can be assembled and dismantled easily and repeatedly
with small transportation size. The lifespan of aluminium framework
can reach 20-30 years, and 10-20 years for PVC fabrics depending on
different conditions of usage.
Q: What documents are available?
A full range documents including structural drawings, packing list,
installation manual and relative certificates can be provided.
Moreover, customs declaration is provided. We provide one-stop
service for you.
For more questions please kindly contact me, thank you.
