Fire Resistant Certified PVC Tarpaulins Storage Tents For
Commercial Or Industrial Use
We have a vast selection of storage tents are available in
different colours, sizes and qualities. Are you looking for a
storage tent that is great value for money or extremely high and
fire-resistant? Perhaps even with statics? No problem! You will
find the product to suit your need, from the solid compact range to
the exclusive upper range.
Whether for private, commercial or industrial use, the
possibilities of a storage tent are diverse. For example, it could
be used as a sheltered storage and working are, as a protected
space for your vehicle and machines or in the agricultural sector
as a barn of tent for livestock. You will find small storage tents
of 3x2 m to enormous halls of 10x20 m, for example. The products
are available in different wall heights from 2 to 4 m. Our
different product lines of storage tents are designed for
year-round use and are extremely durable. All frame constructions
are fully-galvanised, thus anti-corrosive. Only robust, durable PVC
tarpaulin material is used that is 100% waterproof and provides
high UV protection. The PVC tarpaulins are
fire-resistant-certified. Due to being robust and durable, our
storage tents are an outstanding alternative to a permanent
building structure.
Product Description
Tents structure material:
High Reinforce Aluminum, anti-rust surface, GB6061-T6;
Tents fabric material:
Cover material is 850 g/m2 for tent roof and 650 g/m2
Double PVC-Coated Polyester for walls.
Flame retardant, UV resistance, waterproof, comply to DIN 4102 B1,
M2
Tent connector: strong hot-dip galvanized steel
and all of our tents can stand -30°to +70°temperature
Max wind speed allowance: 120km/h.
Tent Specifications
| 1. high pressed extruded aluminum alloy 6061-T6, stainless,
lightweight, durable, 48X84X3mm for 3-10m tent |
| 2. 68x122x3mm, 88x166x3mm, 108x150x3mm,102x203x4mm for 10-20m tent |
| 3. 113x259x4mm, 120x300x5mm for 20-40m tent |
| 4. 120x350x6mm for 40-50m tent |
| Steel parts | hot-dipped galvanized steel |
| Top roof fabric | 850g/sqm double coated pvc, block-out, waterproof , flame retardant
meet M2, B1, DIN4102 standard |
| Side panels(optional) | (1) 650g/sqm double coated pvc, translucent, waterproof, flame
retardant meet M2, B1, DIN4102 standard, or; |
| (2) 950g/sqm transparent pvc fabric |
| (3) solid walls: glass panel, sandwich panels, ABS panels, color
steel sheet |
| Allowed temperature | -20° to 70° environment |
| Max wind loading capacity | 120km/hour |
| Snow loading | 30kg/sqm |
Tent Capacity & Advantages
What are the advantages of industrial warehouse tents?
Now it is a common phenomenon that the storage of goods is difficult for enterprises, but in fact, there are many reasons
for the urgency of enterprises' warehouses, such as the peak season
of the industry, the rapid expansion of business scale, and the
lack of warehouse planning. To solve this problem, warehouse tent
is the best choice.
As a temporary storage place, warehouse tent can also be used as a
long-term cargo storage plan. It is simple to build. The area of
tent can be customized design and production according to the actual needs of customers. The
span can be 3m-60m, with unlimited length. The size of the space
can be adjusted, it can also be built repeatedly, it can be moved,
and the location can be changed. The overall system is very environmentally friendly.
Choose the warehouse tent to help you solve the emergency problems
and get through the difficult period. At the same time, it can also
be used for a long time to save costs.
Tent Measurement Chart
Tent Width:3m-50m
Tent Length no limited. Extended length of tent by 5m a bay, such as
15m,20m,25m,30m,35m,40m......
Customized size is available
| Product Code | Tent Span | Tent partition width | Eave height | Roof height | Angle of Roof | Aluminium profile size(mm) |
| SHB-6 | 6 | 3 | 2.6 | 3.7 | 20° | 84X48X3 |
| SHB-8 | 8 | 3 | 2.6 | 4 | 20° | 84X48X3 |
| SHB-9 | 9 | 3 | 2.6 | 4.3 | 20° | 84X48X3 |
| SHB-10 | 10 | 5 | 2.6 | 4.8 | 20° | 122X68X3 |
| SHB-12 | 12 | 5 | 3 | 5.2 | 20° | 122X68X3 |
| SHB-15 | 15 | 5 | 4 | 6.4 | 18° | 166X88X3 |
| SHB-18 | 18 | 5 | 4 | 6.9 | 18° | 203X112X4 |
| SHB-20 | 20 | 5 | 4 | 7.2 | 18° | 203X112X4 |
| SHB-25 | 25 | 5 | 4 | 8 | 18° | 203X112X4 |
| SHB-30 | 30 | 5 | 4 | 8.9 | 18° | 250X120X5 |
| SHB-35 | 35 | 5 | 4 | 9.8 | 18° | 300X120X5 |
| SHB-40 | 40 | 5 | 4 | 10.6 | 18° | 300X120X5 |
| SHB-45 | 45 | 5 | 4 | 11.4 | 18° | 300X120X5 |
| SHB-50 | 50 | 5 | 4 | 12.3 | 18° | 350X120X5 |
| SHB-55 | 55 | 5 | 4 | 13.2 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 4 | 14.4 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 6 | 16.4 | 18° | 400X120X5 |
FAQ
Q: How can I place order?
After all details has been discussed and confirmed with us, we can
start production from the date of payment deposit 30% received.
After finished production, you can pay the balance payment, we will
arrange shipment.
The payment terms is 30% depoit and 70% balance before shipment by
T/T transfer.
Q: What's the production lead time?
Our production lead time is 7-30 days depends on the exact order.
Q: What about the shipment?
We provide CIF, FOB or EXW.
CIF: We arrange shipment from our factory to your sea port.
FOB: We arrange shipment from our factory to the sea port from our
side.
EXW: We don’t arrange shipment and you will work the shipment with
your shipping agent.
Q:Do you have certifications?
Yes, we have SGS certificates, Including low temperature bending
resistance certification, Scarlett 650g anti-UV4-5 certified,
UV-resistant and certified mold proofing antibacterial, flame
retardant certification 650gsm-B1, 850gsm-M2 flame retardant
certification.
Q: Can you print our logos on the tent?
Yes. Customized logos can be printed on the tent fabric according
to your requirements.
Q: Is that factory price?
Yes. We assure you all prices are based on factory.
Q: Does your tent be able to installed repeatedly? What is the life
span?
Our tents can be assembled and dismantled easily and repeatedly
with small transportation size. The lifespan of aluminium framework
can reach 20-30 years, and 10-20 years for PVC fabrics depending on
different conditions of usage.
Q: What documents are available?
A full range documents including structural drawings, packing list,
installation manual and relative certificates can be provided.
Moreover, customs declaration is provided. We provide one-stop
service for you.
For more questions please kindly contact me, thank you.
